ZL926C 1.6 Ton 4.2m Length Arm Wheel Loader

Categories	Wheel Loaders
Brand	Saintyol DAWIN Construction Machinery Manufacturer
Model	ZL926C
bucket capacity(m3)	0.75
Rated Load (kg)	1600
dumping height(mm)	4100-4200
rated power(kw)	55KW
FOB port	Qingdao
Terms of Payment	L/C, T/T
Download DOC
Update Time	Apr 20,2024

Contact Now

Favorites

Detail Information

Instruction:

Wheel Loader is a kind of front wheel loader with single bucket ,articulated and hydraulic unloading. It has been developed and designed in accordance with user requirements, reference models after absorption of domestic and similar structural features and advanced technology.

Wheel loader is widely used in the construction, municipal engineering, urban and rural gardens, lime, sand, cement factories, mines and other enterprises and institutions and departments. It is paticularly applied to the narrow space for the loading operation of stone,sand and other construction materials.The main components of the loader are used brand-name manufacturer's products, interchangeability of good, reliable, well-resourced parts.

Pictures:

Main Features:

Main Features

1.Adopting hydraulic-mechanical transmission that can make the best use of engine power, realize automatic continuously variable transmission(CVT) according to the external resistance, avoid engine stall due to the sudden increase in external load, and can also absorb and eliminate the vibration and shock of the external load to the engine to protect the transmission system and the engine and improve the service life of the whole machine, which make the machine easy and comfortable to operate and have higher economical and production efficiency;

2.Saintyol DAWIN wheel loaders adopting central articulated frame and load-sensing hydraulic steering gear that can make the track of rear wheels of the wheel loader coincide with the track of its front wheels when turning to make the turning radius short, which enables it to work on a narrow site and makes it have easy and flexible operation, safe and reliable performance, compact structure and easy maintenance;

3.The front end wheel loaders adopting four-wheel drive, low-pressure wide-base off-road tire and pendular rear axle that can make the wheel loader have good off-road performance, traffic ability and more traction;

4.Fully enclosed glass cab with adjustable and suspension seat can provide comfortable driving and wide view. Electric Fan is standard configuration. Air-conditioner is optional.

5.Using 16/70-20 big tyres to increase the stability of whole machine and the service life of tyre.

6.Brake system adopts air pump, air over hydraulic caliper disc brake on 4 wheels;

7.This wheel loader adopts YJ265 split type torque converter, and the whole machine is fully hydraulic transmission;

8.This compact wheel loader can be equipped with pilot control system (joystick control )to make it easy to operate and increase the hydraulic performance of the whole machine;

9.Power system adopts HUANGFENG,4102, 75kW, Turbo-charged, Fuel-Efficient, environmentally friendly, 4-cylinder engine to make this compact wheel loader have strong power and high acceleration, which greatly increase its high working efficiency;

10.This compact wheel loader can be equipped with optional quick hitch , and this quick hitch enables this compact wheel loader to change quickly among multiple attachments, such as hay grapple, grass fork, wood fork, timber grapple, pallet fork, bale grapple, four-in-one bucket, straight snow blade, V-shaped snow plow, snow bucket, drum grab, barrel grapple, snow blower, street sweeper and sand bucket etc.

Specifications:

Performance	Rated load	1600kg
	Overall weight	3600kg
	Rated bucket capacity	0.75m³
	Maximum tractive force	47KN
	Maximum breakout force	≥48KN
	Maximum grade ability	30℃
	Maximum dump height	4100-4200mm
	Maximum dump reach	900m
	Overall dimension (L×W×H)	5400×1900×270mm
	Minimum turning radius	3400mm
Engine	Model	YN27GBZ
	Type	In-line arrangement, water cooling, four-stroke
	No. of cylinder-bore/stroke	4-102×115mm
	Rated power	55kw--2400r/min
	Maximum torque	265N.m
	Min fuel-consume ratio	≤225g/kw.h
Transmission system	Torque converter	265
	Gearbox mode	Power shift normally engaged straight gear
	Gear shift	4 forward shift 4reverse shift
	Maximum speed	30km/h
Drive axles	Main reducing spiral	bevel gear grade 1reduction
	Decelerating mode	planetary reduction,grade 1
	Wheel base (mm)	2140mm
	Wheel tread	1450mm
	Minimum ground clearance	250mm
hydraulic system	System working pressure	16MPa
	bucket lifting time	≤6s
	bucket falling time	≤4s
	total time for a signle working cycle	≤11.5s
	Function of leveling automatically	optional
Brake system	Service brake	air over hydraulic disc brake on 4 wheels
Brake system	Parking brake	manual parking brake
Tyre	Type specification	20.5/70-16
	Front tyre pressure	0.4Mpa
	Rear tyre pressure	0.35Mpa

Main Parts:

Packing & Shipping:

Testing Video:

Wheel Loader E-Brochure Download
